Equipos y Productos: TurboDifusores: DiamanFlat 2 WayCorner.

Características Generales

Este TurboDifusor DiamanFlat 2 WayCorner VentDepot, es de techo tipo diamante de alta capacidad.
Gran apariencia estética que armoniza con detalles arquitectónicos, especialmente en techos modulares.
Fabricada en 2 vías a la esquina con difusión de aire Cuadrado, a la Altura o a la Base.
El núcleo es totalmente removible desde la vista del difusor, lo que facilita su instalación y mantenimiento.
Acabado en pintura electrostática horneada Blanco dober.

Aplicaciones
Para uso en: Cualquier ramo industrial, comercial y residencial.

Garantía

1 (Un) año de Garantía, certificado por escrito, sujeto a las cláusulas.

Características Técnicas Específicas

Clave
Cuadrado
50% 50%
Rectangular
70% 30%
Rectangular
30% 70%
Fondo

Capacidad Máxima de Difusión

Peso y Dimensiones
con Empaque de Plástico
mm pulg mm pulg mm pulg mm pulg m3/hr Kg cm

DFC-001

152x152 6x6 --- --- --- --- 44 1 3/4 225 0.5 16x16x5

DFC-002

--- --- 229x152 9x6 --- --- 44 1 3/4 338 0.6 23x16x5

DFC-003

--- --- --- --- 229x152 9x6 44 1 3/4 338 0.6 23x16x5

DFC-004

229x229 9x9 --- --- --- --- 44 1 3/4 506 0.7 23x23x5

DFC-005

--- --- 305x152 12x6 --- --- 44 1 3/4 450 0.8 31x15x5

DFC-006

--- --- --- --- 305x152 12x6 44 1 3/4 450 0.8 31x15x5

DFC-007

--- --- 305x229 12x9 --- --- 44 1 3/4 675 0.9 31x23x5

DFC-008

--- --- --- --- 305x229 12x9 44 1 3/4 675 0.9 31x23x5

DFC-009

305x305 12x12 --- --- --- --- 44 1 3/4 900 1.0 31x31x5

DFC-010

--- --- 381x152 15x6 --- --- 44 1 3/4 563 1.1 39x16x5

DFC-011

--- --- --- --- 381x152 15x6 44 1 3/4 563 1.1 39x16x5

DFC-012

--- --- 381x229 15x9 --- --- 44 1 3/4 844 1.2 39x23x5

DFC-013

--- --- --- --- 381x229 15x9 44 1 3/4 844 1.2 39x23x5

DFC-014

--- --- 381x305 15x12 --- --- 44 1 3/4 1125 1.3 39x31x5

DFC-015

--- --- --- --- 381x305 15x12 44 1 3/4 1125 1.3 39x31x5

DFC-016

381x381 15x15 --- --- --- --- 44 1 3/4 1406 1.4 39x39x5

DFC-017

--- --- 457x152 18x6 --- --- 44 1 3/4 675 1.5 46x46x5

DFC-018

--- --- --- --- 457x152 18x6 44 1 3/4 675 1.5 46x16x5

DFC-019

--- --- 457x229 18x9 44 1 3/4 1013 1.6 46x23x5

DFC-020

--- --- --- --- 457x229 18x9 44 1 3/4 1013 1.6 46x23x5

DFC-021

--- --- 457x305 18x12 --- --- 44 1 3/4 900 1.7 46x31x5

DFC-022

--- --- --- --- 457x305 18x12 44 1 3/4 900 1.7 46x31x5

DFC-023

--- --- 457x381 18x15 --- --- 44 1 3/4 1688 1.8 46x39x5

DFC-024

--- --- --- --- 457x381 18x15 44 1 3/4 1688 1.8 46x39x5

DFC-025

457x457 18x18 --- --- --- --- 44 1 3/4 2025 1.9 46x46x5
Clave
Cuadrado
50% 50%
Rectangular
70% 30%
Rectangular
30% 70%
Fondo

Capacidad Máxima de Difusión

Peso y Dimensiones
con Empaque de Plástico
mm pulg mm pulg mm pulg mm pulg m3/hr Kg cm

DFC-026

--- --- 534x152 21x6 --- --- 44 1 3/4 788 2.1 54x16x5

DFC-027

--- --- --- --- 534x152 21x6 44 1 3/4 788 2.1 54x16x5

DFC-028

--- --- 534x229 21x9 --- --- 44 1 3/4 900 2.2 54x23x5

DFC-029

--- --- --- --- 534x229 21x9 44 1 3/4 900 2.2 54x23x5

DFC-030

--- --- 534x305 21x12 --- --- 44 1 3/4 1575 2.3 54x31x5

DFC-031

--- --- --- --- 534x305 21x12 44 1 3/4 1575 2.3 54x31x5

DFC-032

--- --- 534x381 21x15 --- --- 44 1 3/4 1969 2.4 54x39x5

DFC-033

--- --- --- --- 534x381 21x15 44 1 3/4 1969 2.4 54x39x5

DFC-034

--- --- 534x457 21x18 --- --- 44 1 3/4 2363 2.5 54x46x5

DFC-035

--- --- --- --- 534x457 21x18 44 1 3/4 2363 2.5 54x46x5

DFC-036

534x534 21x21 --- --- --- --- 44 1 3/4 2756 2.6 54x54x5

DFC-037

--- --- 610x152 24x6 --- --- 44 1 3/4 900 2.7 62x16x5

DFC-038

--- --- --- --- 610x152 24x6 44 1 3/4 900 2.7 62x16x5

DFC-039

--- --- 610x229 24x9 --- --- 44 1 3/4 1350 2.8 62x23x5

DFC-040

--- --- --- --- 610x229 24x9 44 1 3/4 1350 2.8 62x23x5

DFC-041

--- --- 610x305 24x12 --- --- 44 1 3/4 1800 2.9 62x31x5

DFC-042

--- --- --- --- 610x305 24x12 44 1 3/4 1800 2.9 62x31x5

DFC-043

--- --- 610x381 24x15 --- --- 44 1 3/4 2250 3.0 62x39x5

DFC-044

--- --- --- --- 610x381 24x15 44 1 3/4 2250 3.0 62x39x5

DFC-045

--- --- 610x457 24x18 --- --- 44 1 3/4 2700 3.1 62x46x5

DFC-046

--- --- --- --- 610x457 24x18 44 1 3/4 2700 3.1 62x46x5

DFC-047

--- --- 610x534 24x21 --- --- 44 1 3/4 3150 3.2 62x54x5

DFC-048

--- --- --- --- 610x534 24x21 44 1 3/4 3150 3.2 62x54x5

DFC-049

610x610 24x24 --- --- --- --- 44 1 3/4 3600 3.3 62x62x5

DFC-050

--- --- 686x152 27x6 --- --- 44 1 3/4 1013 3.4 69x16x5
Clave
Cuadrado
50% 50%
Rectangular
70% 30%
Rectangular
30% 70%
Fondo

Capacidad Máxima de Difusión

Peso y Dimensiones
con Empaque de Plástico
mm pulg mm pulg mm pulg mm pulg m3/hr Kg cm

DFC-051

--- --- --- --- 686x152 27x6 44 1 3/4 1013 3.4 69x16x5

DFC-052

--- --- 686x229 27x9 --- --- 44 1 3/4 1519 3.5 69x23x5

DFC-053

--- --- --- --- 686x229 27x9 44 1 3/4 1519 3.5 69x23x5

DFC-054

--- --- 686x305 27x12 --- --- 44 1 3/4 2025 3.6 69x31x5

DFC-055

--- --- --- --- 686x305 27x12 44 1 3/4 2025 3.6 69x31x5

DFC-056

--- --- 686x381 27x15 --- --- 44 1 3/4 2532 3.7 69x39x5

DFC-057

--- --- --- --- 686x381 27x15 44 1 3/4 2532 3.7 69x39x5

DFC-058

--- --- 686x457 27x18 --- --- 44 1 3/4 3038 3.8 69x46x5

DFC-059

--- --- --- --- 686x457 27x18 44 1 3/4 3038 3.8 69x46x5

DFC-060

--- --- 686x534 27x21 --- --- 44 1 3/4 3544 3.9 69x54x5

DFC-061

--- --- --- --- 686x534 27x21 44 1 3/4 3544 3.9 69x54x5

DFC-062

--- --- 686x610 27x24 --- --- 44 1 3/4 4050 4.0 69x62x5

DFC-063

--- --- --- --- 686x610 27x24 44 1 3/4 4050 4.0 69x62x5

DFC-064

686x686 27x27 --- --- --- --- 44 1 3/4 4615 4.1 69x69x5

DFC-065

--- --- 762x152 30x6 --- --- 44 1 3/4 1125 4.2 77x16x5

DFC-066

--- --- --- --- 762x152 30x6 44 1 3/4 1125 4.2 77x16x5

DFC-067

--- --- 762x229 30x9 --- --- 44 1 3/4 1688 4.3 77x23x5

DFC-068

--- --- --- --- 762x229 30x9 44 1 3/4 1688 4.3 77x23x5

DFC-069

--- --- 762x305 30x12 --- --- 44 1 3/4 2250 4.4 77x31x5

DFC-070

--- --- --- --- 762x305 30x12 44 1 3/4 2250 4.4 77x31x5

DFC-071

--- --- 762x381 30x15 --- --- 44 1 3/4 2813 4.5 77x39x5

DFC-072

--- --- --- --- 762x381 30x15 44 1 3/4 2813 4.5 77x39x5

DFC-073

--- --- 762x457 30x18 --- --- 44 1 3/4 3375 4.6 77x39x5

DFC-074

--- --- --- --- 762x457 30x18 44 1 3/4 3375 4.6 77x46x5

DFC-075

--- --- 762x534 30x21 --- --- 44 1 3/4 3938 4.7 77x54x5
Clave
Cuadrado
50% 50%
Rectangular
70% 30%
Rectangular
30% 70%
Fondo

Capacidad Máxima de Difusión

Peso y Dimensiones
con Empaque de Plástico
mm pulg mm pulg mm pulg mm pulg m3/hr Kg cm

DFC-076

--- --- --- --- 762x534 30x21 44 1 3/4 3938 4.7 77x54x5

DFC-077

--- --- 762x610 30x24 --- --- 44 1 3/4 4500 4.8 77x62x5

DFC-078

--- --- --- --- 762x610 30x24 44 1 3/4 4500 4.8 77x62x5

DFC-079

--- --- 762x686 30x27 --- --- 44 1 3/4 5063 4.9 77x69x5

DFC-080

--- --- --- --- 762x686 30x27 44 1 3/4 5063 4.9 77x69x5

DFC-081

762x762 30x30 --- --- --- --- 44 1 3/4 5625 5.0 77x77x5

| Orden de Compra | Solicitar Precios | Correo y/o Asesoría Técnica | AutoCad| Tiempos de Entrega | Garantía |

Montaje

Perforar panel o tabla roca al tamaño correspondiente al difusor, conectar a difusor y descansar el TurboDifusor DiamanFlat 2 WayCorner sobre el marco.

VentDepot Team, monta, instala o da mantenimiento a cualquiera de nuestros equipos, de forma rápida, segura y conforme a las normas industriales.

Suministro y servicio a toda la República Mexicana.

Dimensiones

Clave A B C D E

DFC-034

534 457 44 610 534

DFC-035

534 457 44 610 534

DFC-036

534 534 44 610 610

DFC-037

610 152 44 686 229

DFC-038

610 152 44 686 229

DFC-039

610 229 44 686 305

DFC-040

610 229 44 686 305

DFC-041

610 305 44 686 381

DFC-042

610 305 44 686 381

DFC-043

610 381 44 686 457

DFC-044

610 381 44 686 457

DFC-045

610 457 44 686 534

DFC-046

610 457 44 686 534

DFC-047

610 534 44 686 610
Clave A B C D E

DFC-048

610 534 44 686 610

DFC-001

152 152 44 229 229

DFC-049

610 610 44 686 686

DFC-002

229 152 44 305 229

DFC-050

686 152 44 762 229

DFC-003

229 152 44 305 229

DFC-051

686 152 44 762 229

DFC-004

229 229 44 305 305

DFC-052

686 229 44 762 305

DFC-005

305 152 44 381 229

DFC-053

686 229 44 762 305

DFC-006

305 152 44 381 229

DFC-054

686 305 44 762 381

DFC-007

305 229 44 381 305

DFC-055

686 305 44 762 381

DFC-008

305 229 44 381 305

DFC-056

686 381 44 762 457

DFC-009

305 305 44 381 381

DFC-057

686 381 44 762 457

DFC-010

381 152 44 457 229

DFC-058

686 457 44 762 534

DFC-011

381 152 44 457 229

DFC-059

686 457 44 762 534

DFC-012

381 229 44 457 305

DFC-060

686 534 44 762 610

DFC-013

381 229 44 457 305

DFC-061

686 534 44 762 610

DFC-014

381 305 44 457 381

DFC-062

686 610 44 762 686

DFC-015

381 305 44 457 381

DFC-063

686 610 44 762 686

DFC-016

381 381 44 457 457

DFC-064

686 686 44 762 762

DFC-017

457 152 44 534 229

DFC-065

762 152 44 838 229

DFC-018

457 152 44 534 229

DFC-066

762 152 44 838 229

DFC-019

457 229 44 534 305

DFC-067

762 229 44 838 305

DFC-020

457 229 44 534 305

DFC-068

762 229 44 838 305

DFC-021

457 305 44 534 381

DFC-069

762 305 44 838 381

DFC-022

457 305 44 534 381

DFC-070

762 305 44 838 381

DFC-023

457 381 44 534 457

DFC-071

762 381 44 838 457

DFC-024

457 381 44 534 457

DFC-072

762 381 44 838 457

DFC-025

457 457 44 534 534

DFC-073

762 457 44 838 534

DFC-026

534 152 44 610 229

DFC-074

762 457 44 838 534

DFC-027

534 152 44 610 229

DFC-075

762 534 44 838 610

DFC-028

534 229 44 610 305

DFC-076

762 534 44 838 610

DFC-029

534 229 44 610 305

DFC-077

762 610 44 838 686

DFC-030

534 305 44 610 381

DFC-078

762 610 44 838 686

DFC-031

534 305 44 610 381

DFC-079

762 686 44 838 762

DFC-032

534 381 44 610 457

DFC-080

762 686 44 838 762

DFC-033

534 381 44 610 457

DFC-081

762 762 44 838 838

Cualidades

Vista posterior. Soportes rígidos que le dan una buena resistencia a los álabes difusores.

Sumamente ligero y fácil de instalar, brindando un aspecto estético y funcional.

Vista lateral, diseño altamente estético y discreto.
